MW RSP-150-7.5 :: switching power supply, PFC, 150 W, 7,5 V / 20 A
SNT case 150W 7,5V/20A
Product Description
Technical information
General
Type
Switching power supply
Design
Closed
Electrical values
Voltage
7.5 V
Current
20
Input voltage
88 - 264 VAC
Input voltage
120 - 370 VDC
Efficiency
88.5 %
Making current
40 A
Ripple
100 mV
Specials
Short circuit protected
Yes
Overload protection
Yes
Interfaces
Connection
Screw terminals
Packaging
Packaging
Individual packaging
Measures
Length
199 mm
Width
99 mm
Height
30 mm
Enclosed case, screw terminals
Universal input
Overload protection, current limiting, auto recovery
Protections: short circuit/over load/over voltage
Built-in active PFC function
Low profile
Built-in remote On/Off control
output voltage: 7,5 V DC
output current: 20,0 A
power: 150 W
Ripple&Noise: 100 mVpp
efficiency: 88,5%
dimensions: 199 x 99 x 30 mm / 600 g
